Byk Ep Fuga 2002-2K
Two Component Epoxy Based Joint Filler
BYK EP FUGA 2002–2K it is two-component epoxy based joint sealaer used for ceramic, marble, granite, glass mosaic and glass brick. It is resistant to chemicals, bacteria, easy to apply, can be cleaned with water.
Places of Usage
• Indoors and outdoors.
• Filling the joints of ceramic, marble, granite, acid-resistant ceramic, porcelain ceramic, glass mosaic and glass brick joints
adhered to existing surfaces.
• All kinds of food production facilities,
• Meat and fish industry, slaughterhouses,
• Pharmaceutical, paint, paper, battery and fertilizer industries,
• Printing houses, industrial kitchens and laundries, dining halls,
• All kinds of hygienic environments in hospitals,
• Swimming pools and thermal pools,
• Waste water and treatment plants,
• Shopping malls, terminals etc. exposed to heavy pedestrian traffic.
Advantages
• Resistant to chemicals, acids, alkalis, oils, food waste water,domestic waste water, chemical waste water.
• It has antibacterial properties. Does not form mold, fungus and bacteria.
• High mechanical strength.
• Does not retain dirt, easy to clean.
• Suitable for joint widths from 2 mm to 10 mm.
• Resistant to freeze-thaw cycle.
• Can be used in drinking water contact
Technical Specifications
Color |
Ral Colors |
Hardness |
75-80 Shore D |
Miture Pot Life |
40-45 min |
Full Curing |
7 Days |
Abrasion Resistant |
76 N/mm3 |
Flexural Strength |
32,2 N/mm2 |
NOTE: Flammable and exploision products should be kept away during the application. Protective gloves and masks should be used for hands and eyes during application. The product should be used in well ventilated environments.If the material comes into contact with eyes, it should be washed immediately with su¬cient water. Childrens should kept away from the product. For more detailed information, ask for the Safety Data Sheet (MSDS).
Surface Preparation
The surface should be cleaned with a high pressure washer, removing oil, grease, fuel and paraffin residues, as well as mold release agents, cement residues, chips, loose particles and cured membranes
Application
BYK EP FUGA 2002–2K, It is filled into the joints with a plastic or hard rubber trowel or with the help of a muzzle-loading gun. Excess material is scraped from the joints. In deep joints, the first applied material collapses in the joint. Make sure that the joint is completely filled. Wait for 15 to 30 minutes depending on the ambient and surface temperature, clean the surface with a suitable sponge and hot detergent water and finalize the joints. The sponge should be changed frequently
Packaging
A =4 kg + 1,5 kg metal packaging
Consumption
Joint Width (mm) |
Joint Depth (mm) |
Ceramic Dimensions (mm) |
Consumption (gr/m²) |
| 3 | 14 | 115x240 | 1050 |
| 3 | 15 | 115x240 | 1100 |
| 3 | 14 | 240x240 | 750 |
| 3 | 7 | 200x200 | 400 |
| 3 | 7 | 250x250 | 350 |
| 3 | 8,5 | 300x300 | 350 |
| 3 | 9 | 300x600 | 250 |
| 3 | 9 | 330x500 | 250 |
| 3 | 9 | 400x400 | 250 |
| 3 | 12 | 600x600 | 250 |
| 4 | 14 | 115x240 | 1400 |
| 4 | 15 | 115x240 | 1400 |
| 4 | 15 | 240x240 | 1000 |
| 4 | 7 | 200x200 | 550 |
| 4 | 7 | 250x250 | 450 |
| 4 | 8,5 | 300x300 | 450 |
| 4 | 9 | 300x600 | 350 |
| 4 | 9 | 330x350 | 350 |
| 4 | 9 | 400x400 | 350 |
| 4 | 12 | 600x600 | 300 |
| 5 | 14 | 115x240 | 1780 |
| 5 | 15 | 115x240 | 1850 |
| 5 | 15 | 240x240 | 1200 |
| 5 | 7 | 200x200 | 700 |
| 5 | 7 | 250x250 | 850 |
| 5 | 8,5 | 300x300 | 550 |
| 5 | 9 | 300x600 | 450 |
| 5 | 9 | 330x500 | 450 |
| 5 | 9 | 400x400 | 450 |
| 5 | 12 | 600x600 | 400 |
| 7 | 14 | 115x240 | 2400 |
| 7 | 15 | 115x240 | 2600 |
| 7 | 15 | 240x240 | 1700 |
| 7 | 7 | 200x200 | 950 |
| 7 | 7 | 250x250 | 750 |
| 7 | 8,5 | 300x300 | 750 |
| 7 | 9 | 300x600 | 600 |
| 7 | 9 | 330x500 | 600 |
| 7 | 9 | 400x600 | 600 |
| 7 | 12 | 600x600 | 550 |
| 10 | 14 | 115x240 | 3500 |
| 10 | 15 | 115x240 | 3650 |
| 10 | 15 | 240x240 | 2400 |
| 10 | 7 | 200x200 | 1350 |
| 10 | 7 | 250x250 | 1100 |
| 10 | 8,5 | 300x300 | 1100 |
| 10 | 9 | 300x600 | 900 |
| 10 | 9 | 330x500 | 900 |
| 10 | 9 | 400x400 | 900 |
| 10 | 12 | 600x600 | 800 |
Shelf Life
It can be stored in its original unopened buckets in dry conditions at temperatures between 5°C and 25°C for a minimum of 12 months. Containers of unmixed components must be kept hermetically sealed until the next use.
Safety Precautions
Flammable and combustible products should be kept away during application. No smoking. Take care to ensure continuous ventilation of the application area. Protective equipment such as goggles and gloves should be used during application. In case of eye contact, rinse thoroughly with plenty of water. Ask for Material Safety Data Sheet for detailed information. Keep out of the reach of children. The product must be used by professional users, taking into account the data in the technical information section.
